PE (Vertical Sealless Pump)

●PE  Vertical Sealless Pump
● Tough Construction against high corrosive and high temperature chemical liquids
● Power: 1, 2, 3 HP
● Frequency: 50/60HZ
● Motor: 2 Poles
● Agency Listing: CE, CSA, C-US Mark
● Maximum Permissible Temperature: 70 ºC

 Download Spesifications



60 Hz Specification:  3450 RPM
Type S.G. Motor Pump Wt. Height. Pump
Dia.
Power Phase Volt Bore Size Max.
Head		 Max.
Flow
HP kW PH V Inlet
Inch (mm)		 Outlet
inch (mm)		 m m³/min kG mm mm
PE-0532N 1.0 0.5 0.4 3 220 ~ 460 2" (50) 1" (25) 10 0.19 19.4 536 221
PE-132N 1.0 1 0.75 3 220 ~ 460 2"(50) 1.5"(40) 12 0.25 20 530 221
PE-232N 1.0 2 1.5 3 220 ~ 460 2"(40) 1.5"(40) 16 0.30 23 610 221
PE-332N 1.0 3 2.2 3 220 ~ 460 2"(50) 1.5"(40) 16 0.38 35 610 221
