MCP (Volute Pump) for Irrigation

● MCP Volute Pumps
● Power:1 ~ 3HP
● Motor: 2 pole
● Impeller: Bronze
● MCP 112AN/132AN (1HP x 2) - 11/2 HP x 2 - 2-3 HP

Download Spesifications





Specifications:

Type Motor Pump Wt.
Power Phase Volt Bore Max.Head Max.Flow
HP PH V Inch M L/min Kg
MCP-111AN 1 1 110 2" 18 300 38
MCP-112AN 220
MCP-132AN 3 220 ~ 440
MCP-111 1.5 1 110 2" 18 270 18
MCP-112 220
MCP-132 3 220 ~ 440
MCP-212L 2 1 220 3" 20 1,000 46
MCP-232L 3 220 ~ 440
MCP-312 3 1 220 4" 22 1,200 54
MCP-332 3 220 ~ 440
